When companies require a custom granite precision surface plate, one of the first questions is: What information needs to be provided to the manufacturer? Supplying the right parameters is essential to ensure the plate meets both performance and application requirements.
As global demand for high-accuracy measuring equipment continues to grow, ZHHIMG® reminds customers that every granite surface plate is unique. Here are the main parameters you should prepare before starting a customization project.
1. Dimensions (Length, Width, Thickness)
The overall size of the plate is the most fundamental parameter.
-
Length & Width determine the working area.
-
Thickness is linked to stability and load-bearing capability. Larger plates usually require greater thickness to prevent deformation.
Providing accurate dimensions allows engineers to calculate the optimal balance between weight, rigidity, and transport feasibility.
2. Load-Bearing Requirements
Different industries require different load capacities. For instance:
-
A plate for general metrology labs may only need moderate load resistance.
-
A plate for heavy machinery assembly may require significantly higher bearing capacity.
By specifying expected loads, the manufacturer can select suitable granite grade and support structure.
3. Accuracy Grade
Granite surface plates are classified by accuracy levels, commonly following DIN, GB, or ISO standards.
-
Grade 0 or Grade 00: High-precision measurement and calibration.
-
Grade 1 or Grade 2: General inspection and workshop applications.
The choice of grade should align with the precision requirements of your measurement tasks.
4. Application & Usage Environment
Usage scenarios provide critical insight for design.
-
Laboratories require stable, vibration-free platforms with the highest accuracy.
-
Factories may prioritize durability and ease of maintenance.
-
Cleanroom or semiconductor industries often require specific surface treatments or anti-contamination considerations.
Sharing your intended application ensures the granite plate is tailored for performance and longevity.
5. Special Features (Optional)
Beyond the basics, customers can request additional customization:
-
Engraved reference lines (coordinate grids, center lines).
-
Threaded inserts or T-slots for mounting.
-
Supports or stands designed for mobility or vibration isolation.
These features should be communicated in advance to avoid post-production modifications.
Conclusion
A custom granite precision surface plate is not just a measuring tool; it is the foundation for reliable inspection and assembly in many industries. By providing dimensions, load requirements, accuracy grade, usage environment, and optional features, customers can ensure that their order matches their operational needs perfectly.
ZHHIMG® continues to deliver high-quality customized granite solutions, helping industries achieve superior precision and long-term stability.
