While the surface plate provides the foundational “zero” plane for any inspection task, high-precision manufacturing requires more than just flatness. Modern engineering challenges—such as calibrating a 5-axis CNC mill or aligning a semiconductor lithography stage—demand tools that can define verticality, parallelism, and multi-axis squareness with absolute certainty. To meet these rigorous standards, ZHHIMG provides a suite of specialized geometric references: the Granite Tri Square Ruler, Granite V Blocks, Granite Parallels, and Granite Cubes.
The shift toward “micron-tight” tolerances means that traditional steel setup blocks are often no longer sufficient. Steel is prone to thermal drift and magnetic interference, and even a microscopic burr from a dropped tool can ruin an entire day’s worth of calibration data. By utilizing black granite, ZHHIMG offers tools that are naturally inert, vibration-dampening, and dimensionally stable.
The X-Y-Z Guardian: The Granite Tri Square Ruler
For engineers tasked with checking the perpendicularity of machine tool axes, the granite tri square ruler is an indispensable asset. Unlike a standard flat square, a tri-square provides a stable base and a vertical reference edge that allows for simultaneous checking of the X, Y, and Z axes.
When placed horizontally, it acts as a 90-degree reference for X-Y squareness. When mounted vertically, it allows a probe to trace along its edge to verify the perpendicularity of the Z-axis. At ZHHIMG, we manufacture our tri-squares from premium black granite, often featuring lightened designs with through-holes to make them manageable for field service technicians without compromising the structural rigidity required for “Grade AA” accuracy.
Precision Workholding: The Granite V Block
The measurement of cylindrical parts—such as high-speed spindles, automotive camshafts, or aerospace pins—requires a reference that can hold a round object perfectly parallel to a surface plate. This is the primary function of the granite V block.
Standard steel V blocks can rust or lose their precision over time due to repeated contact with heavy workpieces. ZHHIMG’s granite V blocks are supplied in matched pairs, ensuring that the “V” is centered and parallel to the base and sides within microns. Because black granite is harder than most steels, these blocks resist scratching and maintain their geometry even under the pressure of heavy industrial components. They are the preferred choice for inspecting roundness and run-out in high-stakes quality control environments.
Defining Parallelism: The Role of Granite Parallels
In many setup and inspection routines, workpieces must be elevated to allow for the measurement of stepped features or through-holes. This is where granite parallels become vital. While steel parallels are common in machine shops, granite parallels are the standard for the metrology lab.
Available in two-face or four-face finished versions, ZHHIMG granite parallels are used to create a perfectly parallel “bridge” across a surface plate. Because they are non-magnetic, they are ideal for holding parts that will be measured with electronic sensors or laser scanners that might be sensitive to the magnetic fields often found in hardened steel tools. Our parallels are lapped to ensure that the top and bottom surfaces are parallel to each other within tolerances as tight as 0.002mm per 300mm.
The Ultimate Geometric Standard: The Granite Cube
If there is one tool that represents the pinnacle of geometric metrology, it is the granite cube. Finished on all six sides to a high degree of flatness, squareness, and parallelism, a granite cube acts as a “universal master.”
Whether you are checking the alignment of a coordinate measuring machine (CMM) or setting up a complex jig, a granite cube provides a stable, multi-faced reference. At ZHHIMG, we offer cubes in various sizes, each equipped with threaded inserts for easy handling. A single “Grade 00″ cube can replace several smaller squares and parallels, providing a consolidated reference point that simplifies the calibration of complex 3D geometries.
The ZHHIMG Advantage in Black Granite
The effectiveness of these tools depends entirely on the quality of the stone and the skill of the lapping technician. ZHHIMG uses fine-grained black granite because it has a higher modulus of elasticity and lower water absorption than lighter, grey varieties. This translates to a tool that is less likely to “sag” under its own weight and more resistant to the humid conditions found in some manufacturing plants.
Every tool—whether it is a granite V block or a massive granite cube—undergoes a rigorous certification process. We use electronic levels and autocollimators to verify that every face meets international standards (such as DIN 876 or ASME B89). When you receive a ZHHIMG tool, you aren’t just receiving a piece of stone; you are receiving a traceable physical constant.
Building a Foundation for Precision
As industries move toward fully automated, high-speed production, the “mechanical” accuracy of the setup remains the limiting factor. You cannot calibrate a nanometer-precise machine using a millimeter-precise tool. By integrating granite tri-squares, V blocks, parallels, and cubes into your workflow, you eliminate variables and ensure that your measurement data is anchored in physical reality.
ZHHIMG is proud to be a partner to the world’s most demanding engineering firms. We invite you to contact our technical team to discuss how our specialized granite metrology tools can enhance your inspection capabilities and reduce the margin of error in your manufacturing processes.
