When inspecting granite mechanical parts with straightedges, proper measurement techniques are critical for maintaining accuracy and equipment longevity. Here are five essential guidelines for optimal results:
- Verify Calibration Status
Always confirm the straightedge’s calibration certificate is current before use. Precision granite components demand measurement tools with certified flatness (typically 0.001mm/m or better). - Temperature Considerations
- Allow 4 hours for thermal stabilization when moving between environments
- Never measure components outside 15-25°C range
- Handle with clean gloves to prevent thermal transfer
- Safety Protocol
- Confirm machine power is disconnected
- Lockout/tagout procedures must be implemented
- Rotating part measurements require special fixturing
- Surface Preparation
- Use lint-free wipes with 99% isopropyl alcohol
- Inspect for:
• Surface defects (＞0.005mm)
• Particulate contamination
• Oil residue - Illuminate surfaces at 45° angle for visual inspection
- Measurement Technique
- Apply 3-point support method for large components
- Use 10N maximum contact pressure
- Implement lift-and-reposition movement (no dragging)
- Record measurements at stabilized temperature
Professional Recommendations
For critical applications:
• Establish measurement uncertainty budget
• Implement periodic tool verification
• Consider CMM correlation for high-tolerance parts
Our engineering team provides:
✓ ISO 9001-certified granite components
✓ Custom metrology solutions
✓ Technical support for measurement challenges
✓ Calibration service packages
Contact our metrology specialists for:
- Granite straightedge selection guidance
- Measurement procedure development
- Custom component fabrication
