Precision Granite Surface Plate | ZHHIMG® Ultra-Precision Platform

Short Description:

Premium black granite surface plate manufacturer. Density 3100kg/m³, flatness ≤0.5μm/m, Grade 00 certified. Trusted by GE, Samsung. ISO9001/CE certified.

Brand: ZHHIMG 鑫中惠 Sincerely | 中惠 ZHONGHUI IM

Min. Order Quantity: ≥1 Piece

Supply Ability: 100,000 Pieces per Month

Payment Item: EXW, FOB, CIF, CPT, DDU, DDP...

Origin: Jinan city, Shandong Province, China

Executive Standard: DIN, ASME, JJS, GB, Federal...

Precision : Better than 0.001mm (Nano technology)

Authoritative Inspection Report: ZhongHui IM Laboratory

Company Certificates: ISO 9001; ISO 45001, ISO 14001, CE, SGS, TUV, AAA Grade

Packaging : Custom Export Fumigation-free Wooden Box

Products Certificates: Inspection Reports; Material Analysis Report; Certificate of conformity；Calibration Reports for Measuring Devices

Lead Time: 10-15 workdays

Send email to us

Product Detail

Quality Control

Certificates & Patents

ABOUT US

CASE

Product Tags

The ZHHIMG® Difference: Material Science Meets Generations of Craft

ZHHIMG® precision granite platforms are machined from proprietary Jinan Black granite, quarried from formations in Shandong Province with mineral compositions specifically suited for metrology applications. Our density of 3100kg/m³ — verified on every incoming batch — exceeds European and American alternatives by 10-15%.

What does that mean in practice? Higher compressive strength. Lower water absorption (<0.1% vs. 0.3-0.5% for imported stone). Thermal expansion coefficients half that of lower-density materials.

Our environment isn't a factory floor. It's a metrology lab.

Our 10,000m² climate-controlled workshop maintains temperature stability within ±0.5°C. The floor? A meter-thick reinforced concrete slab with 500mm-wide, 2-meter-deep vibration isolation trenches surrounding every production cell. The overhead cranes are whisper-quiet — literally designed for silence.

Because we learned this the hard way: a granite plate ground in a vibrating factory, shipping in a warm truck, arriving in your climate-controlled lab — that's not precision. That's wishful thinking.

Our craftsmen have been doing this longer than most competitors have existed.

The technicians who perform final hand-lapping on ZHHIMG® Grade 00 surfaces have 30+ years of experience. Not "trained in" — lifetime apprenticeship. They can feel a 0.5-micron high spot under fingertips, adjust pressure by intuition built over decades, and verify flatness by methods that predate electronic instruments.

We don't apologize for combining CNC precision with hand craftsmanship. We embrace it. Because some things machines can't replicate: judgment, experience, the sense of touch that separates "within tolerance" from "precisely right."

Overview

Model	Details	Model	Details
Size	Custom	Application	CNC, Laser, CMM...
Condition	New	After-sales Service	Online supports, Onsite supports
Origin	Jinan City	Material	Black Granite
Color	Black / Grade 1	Brand	ZHHIMG
Precision	0.001mm	Weight	≈3.05g/cm³
Standard	DIN/ GB/ JIS...	Warranty	1year
Packing	Export Plywood CASE	After Warranty Service	Video technical support, Online support, Spare parts, Field mai
Payment	T/T, L/C...	Certificates	Inspection Reports/ Quality Certificate
Keyword	Granite Machine Base; Granite Mechanical Components; Granite Machine Parts; Precision Granite	Certification	CE, GS, ISO, SGS, TUV...
Delivery	EXW; FOB; CIF; CFR; DDU; CPT...	Drawings’ format	CAD; STEP; PDF...

Core Competitive Advantages

What Sets ZHHIMG® Apart

1. Premium Material, Not Commodity Stone

Our Jinan Black granite undergoes strict incoming quality control: density verification, mineral composition analysis, internal defect scanning, and thermal expansion coefficient testing. Every batch. No exceptions.

We reject approximately 15% of incoming raw material — stone that other manufacturers would machine and sell.

2. Manufacturing Environment That Respects Precision

Temperature stability: ±0.5°C maintained 24/7/365

Vibration isolation: Proprietary trench design with floating floor sections

Air filtration: ISO 7 cleanroom standards in critical machining areas

Lighting: Controlled to eliminate thermal loading from lighting fixtures

3. Verification Equipment That National Labs Trust

We measure your components with instruments calibrated to the same standards we claim:

· German Mahr electronic comparators (0.5μm resolution)
· Swiss WYLER electronic levels (0.001mm/m sensitivity)
· UK Renishaw laser interferometers (0.1μm/m accuracy)
· Japanese Mitutoyo coordinate measuring systems

4. Multi-Standard Compliance, Not "Pick One"

We don't offer "DIN or ASME, your choice." We manufacture to every major international standard simultaneously:

· Germany: DIN 876, DIN 875, DIN 650
· USA: ASME B89.3.7 / GGG-P-463c
· Japan: JIS B7513
· China: GB/T 20428
· UK: BS 817
· Russia: GOST 10905-1975

5. Supply Chain You Can Bet Your Production On

We maintain 20,000 units monthly production capacity — enough to supply OEM volume orders without compromising craft attention. Our largest customers (you've heard of them: GE, Samsung, Apple, Oracle) don't wait 6 months for delivery. They have supply agreements, allocated capacity, and priority fulfillment.

Quality Control

We use various techniques during this process:

● Optical measurements with autocollimators

● Laser interferometers and laser trackers

● Electronic inclination levels (precision spirit levels)

5c63827f-ca17-4831-9a2b-3d837ef661db1-300x200

Quality Control

1. Documents together with products: Inspection reports + Calibration reports(measuring devices) + Quality Certificate + Invoice + Packing List + Contract + Bill of Lading(or AWB).

2. Special Export Plywood Case: Export fumigation-free wooden box.

3. Delivery:

Ship	Qingdao port	Shenzhen port	TianJin port	Shanghai port	...
Train	XiAn Station	Zhengzhou Station	Qingdao	...
Air	Qingdao Airport	Beijing Airport	Shanghai Airport	Guangzhou	...
Express	DHL	TNT	Fedex	UPS	...

FAQ

Q: How do I determine the right flatness grade for my application?

A: The 3:1 rule provides a good starting point: your surface plate should be 3x more accurate than the tolerance you're measuring. For CMMs with ±5μm tolerances, Grade 00 (≤0.5μm/m) is appropriate. For production inspection stations with ±20μm tolerances, Grade 0 (≤1.0μm/m) is sufficient.

The tricky part: environmental factors. If your facility has temperature swings >2°C daily, consider upgrading one grade — the thermal stability margin protects your tolerances during non-ideal conditions.

Q: Can marble or limestone substitute for granite to reduce cost?

A: No. Absolutely not. Marble (calcium carbonate) absorbs moisture, expands inconsistently with humidity changes, and degrades rapidly in workshop environments. We've seen marble plates lose 30% of their flatness within 18 months of installation.

Many low-cost suppliers substitute marble deliberately — it's 40% cheaper and almost impossible to distinguish visually without testing. Always request water absorption certificates and density verification.

Q: What custom configurations can you manufacture?

A: Virtually anything within our dimensional envelope (20m × 4m × 1m). Common custom features include:

· Through-holes with specified diameters and locations
· Blind holes for fixture mounting
· T-slots and channel patterns
· Recessed zones for sensor or tooling integration
· Tapered bore holes
· Custom thickness specifications

Standard custom lead time: 3-6 weeks depending on complexity.

Q: How is flatness verified before shipment?

A: Every Grade 00 and Grade 0 plate undergoes minimum 25-point grid measurement using electronic levels or laser interferometers. The measurement grid density increases for larger plates.

We don't ship based on "we think it's good." We ship based on "here's the measured data, here's the calibration certificate, here's the environmental log from measurement time."

Q: What packaging prevents damage during international shipping?

A: Marine-grade crating with:
