High-Precision Custom Granite Machine Base for Semiconductor & Automated Motion Systems
When sub-micron accuracy defines your product's performance, metal machine beds simply can't hold up over time. Thermal expansion, structural resonance, and stress deformation cause microscopic shifts that compromise measurement repeatability.
Engineered from proprietary ZHHIMG® High-Density Black Granite (~3100 kg/m³), this custom-machined granite base delivers unmatched dimensional stability, exceptional damping properties, and lifetime corrosion resistance. Featuring precision-lapped linear guide channels, embedded threaded inserts, and ergonomic handling slots, it serves as the ultimate structural foundation for semiconductor inspection systems, CMM frames, and high-speed linear motor platforms.
|
Model |
Details |
Model |
Details |
|
Size |
Custom |
Application |
CNC, Laser, CMM... |
|
Condition |
New |
After-sales Service |
Online supports, Onsite supports |
|
Origin |
Jinan City |
Material |
Black Granite |
|
Color |
Black / Grade 1 |
Brand |
ZHHIMG |
|
Precision |
0.001mm |
Weight |
≈3.05g/cm3 |
|
Standard |
DIN/ GB/ JIS... |
Warranty |
1year |
|
Packing |
Export Plywood CASE |
After Warranty Service |
Video technical support, Online support, Spare parts, Field mai |
|
Payment |
T/T, L/C... |
Certificates |
Inspection Reports/ Quality Certificate |
|
Keyword |
Granite Machine Base; Granite Mechanical Components; Granite Machine Parts; Precision Granite |
Certification |
CE, GS, ISO, SGS, TUV... |
|
Delivery |
EXW; FOB; CIF; CFR; DDU; CPT... |
Drawings’ format |
CAD; STEP; PDF... |
-
• Proprietary High-Density Black Granite: Sourced specifically for low porosity (< 0.05%) and zero internal stress, guaranteeing long-term resistance to warping and environmental creep.
-
• Integrated Threaded Inserts & Guide Channels: Factory-installed stainless steel inserts and precision-ground linear motion tracks streamline mechanical assembly for optical sensors and linear guides.
-
• Hand-Lapped Sub-Micron Precision: Critical reference planes are hand-lapped by master technicians with over 30 years of experience, achieving nanometer-level flatness and perpendicularity.
-
• Superior Vibration Absorption: Natural crystalline structure dampens high-frequency motor vibrations 15 times faster than cast iron, enabling immediate reading stabilization on CMM and AOI systems.
-
• Zero Corrosion & Non-Magnetic: Completely immune to rust, moisture absorption, and magnetic interference—eliminating the need for protective oils or frequent recalibration.
