Precision Granite Mounting Block with Machined Through-Holes | ZHHIMG®
Most mounting blocks look fine in a spec sheet. Few hold their geometry after five years of thermal cycling and daily mechanical load. That's the gap this granite mounting block is built to close.
Machined from ZHHIMG®'s high-density black granite — measured density approximately 3,100 kg/m³, noticeably denser than standard commercial granite or marble substitutes sometimes passed off as "precision grade" — this block is designed as a stable, non-deforming interface for equipment where positional accuracy can't drift over time. Four precision-bored through-holes, symmetrically positioned in a 2×2 pattern, allow direct mounting to a machine frame, fixture assembly, or sensor housing without introducing secondary adapters that would otherwise add tolerance stack-up.
Unlike cast metal alternatives, this block carries no internal casting stress. It won't creep, warp, or slowly release residual stress the way a machined cast iron equivalent can over years of service — which is exactly why granite has become the default base material across CMMs, optical inspection systems, semiconductor handling stages, and air bearing assemblies.
|
Model |
Details |
Model |
Details |
|
Size |
Custom |
Application |
CNC, Laser, CMM... |
|
Condition |
New |
After-sales Service |
Online supports, Onsite supports |
|
Origin |
Jinan City |
Material |
Black Granite |
|
Color |
Black / Grade 1 |
Brand |
ZHHIMG |
|
Precision |
0.001mm |
Weight |
≈3.05g/cm3 |
|
Standard |
DIN/ GB/ JIS... |
Warranty |
1year |
|
Packing |
Export Plywood CASE |
After Warranty Service |
Video technical support, Online support, Spare parts, Field mai |
|
Payment |
T/T, L/C... |
Certificates |
Inspection Reports/ Quality Certificate |
|
Keyword |
Granite Machine Base; Granite Mechanical Components; Granite Machine Parts; Precision Granite |
Certification |
CE, GS, ISO, SGS, TUV... |
|
Delivery |
EXW; FOB; CIF; CFR; DDU; CPT... |
Drawings’ format |
CAD; STEP; PDF... |
- • No casting stress, no long-term drift. A granite block that measures flat on day one stays flat — cast metal alternatives can still be releasing internal stress five or ten years after machining.
- • Lower thermal expansion than cast iron or aluminum. With a coefficient roughly half that of cast iron, this block introduces less dimensional error per degree of ambient temperature swing — a real factor in fab environments and non-climate-controlled installations.
- • Higher vibration damping than metal equivalents. The dense crystalline structure absorbs mechanical noise that would otherwise transmit through a metal block into whatever it's mounted to.
- • Direct mounting geometry. Four symmetric through-holes mean this block bolts straight into position without adapter plates — fewer interfaces, fewer tolerance stack-ups, less assembly time.
- • Full traceability per unit. The identification plate ties each block back to its own inspection data, not a generic batch claim.
We use various techniques during this process:
● Optical measurements with autocollimators
● Laser interferometers and laser trackers
● Electronic inclination levels (precision spirit levels)
1. Documents together with products: Inspection reports + Calibration reports(measuring devices) + Quality Certificate + Invoice + Packing List + Contract + Bill of Lading(or AWB).
2. Special Export Plywood Case: Export fumigation-free wooden box.
3. Delivery:
|
Ship |
Qingdao port |
Shenzhen port |
TianJin port |
Shanghai port |
... |
|
Train |
XiAn Station |
Zhengzhou Station |
Qingdao |
... |
|
|
Air |
Qingdao Airport |
Beijing Airport |
Shanghai Airport |
Guangzhou |
... |
|
Express |
DHL |
TNT |
Fedex |
UPS |
... |
Is this made from real precision-grade granite, not marble? Yes. Density is verifiable — precision-grade black granite runs close to 3,100 kg/m³, while marble typically sits around 2,600–2,700 kg/m³. We provide density test documentation with every order on request.
Can the hole pattern or dimensions be customized? Yes. This configuration (4 through-holes, 2×2 pattern) is a standard layout, but hole diameter, spacing, block dimensions, and thread specifications can be customized to match your mounting interface. Send us your drawing or a reference part.
What flatness grade can you certify? Flatness grade is confirmed per DIN 876 (or ASME B89 / JIS B 7513 depending on your regional standard) and verified using laser interferometry and calibrated electronic levels, with calibration traceable to a national metrology institute.
How long does a custom order take? Lead time depends on grade and finishing requirements — higher flatness grades (00/0) require additional hand-finishing time. Contact us with your specification for an accurate lead time.
Do you provide inspection reports with each shipment? Yes. Each unit ships with batch-specific inspection data tied to the identification plate fixed to the part, not a generic product-line certificate.
